Trail bikes
250CC HONDA BAJA
Engine Type …………… Single cylinder, four-stroke
Displacement …………… 249.00 ccm (15.19 cubic inches)
Compression Ratio …….. 9.3:1
Maximum Power ……….. 28.00(20.4kW)@8000RPM
Maximum Torque ……… 25.00 Nm (2.5 kgf-m or 18.4 ft.lbs) @ 7000 RPM
Dry weight: …………….. 119.0 kg (262.4 pounds)
Bore x stroke : ………… 73.0 x 59.5 mm (2.9 x 2.3 inches)
Valves per cylinder: …… 4
Front/Rear brakes: …….. Single disc
Wheel Base …………….. 1,420 mm (55.9 inches)
Fuel capacity: ………….. 14.00 litres (3.70 gallons)
250CC T.T.R TAMAHA
|
250CC XR
Engine Type …………… Single cylinder, four-stroke
Displacement …………… 249.00 ccm (15.19 cubic inches)
Compression Ratio …….. 9.3:1
Maximum Power ……….. 28.00(20.4kW)@8000RPM
Maximum Torque ……… 25.00 Nm (2.5 kgf-m or 18.4 ft.lbs) @ 7000 RPM
Dry weight: …………….. 119.0 kg (262.4 pounds)
Bore x stroke : ………… 73.0 x 59.5 mm (2.9 x 2.3 inches)
Valves per cylinder: …… 4
Front/Rear brakes: …….. Single disc
Wheel Base …………….. 1,420 mm (55.9 inches)
Fuel capacity: ………….. 14.00 litres (3.70 gallons)
250CC XR BAJA
Category: ……………….. Enduro / offroad
Engine Type ……………. Single cylinder, four-stroke
Displacement …………… 249.00 ccm (15.19 cubic inches)
Compression Ratio …….. 10.2:1
Maximum Power ……….. 28.00 HP (20.4Kw) @ 8000RPM
Maximum Torque ……… 25.00NM (2.5 KGF-M OR 18.4FT.LBS) @ 7000 RPM
Bore x stroke : …………. 73.0 x 59.5 mm (2.9 x 2.3 inches)
Fuel control: ……………. SOHC
Gearbox: ……………….. 6-speed
Trail: ……………………. 94 mm (3.7 inches)
Front brakes: …………… Single disc
Rear brakes: …………… Single disc
Fuel capacity……………. 9.08 litres (2.40 gallons)
600CC F.M.X
250CC. DIJABEL
Engine type: Single cylinder, four-stroke
Power: 29.50 HP (21.5 kW))
Torque: 27.00 Nm (2.8 kgf-m or 19.9 ft.lbs)
Compression: 7.1:1
Fuel control: DOHC
Cooling system: Oil & air
Gearbox: 6-speed
Transmission type,
final drive: Chain
250CC DR
Engine
Air cooled, four stroke, single cylinder, SOHC, 4 valves
Capacity
249
Bore x Stroke 72 х 61.2 mm
Compression Ratio 8.9:1
Induction
Mikuni VM28SS carbs
Ignition / Starting
Transistorized / kick
Max Power
16.7 hp @ 8700 rpm
Transmission / Drive
5 Speed / chain
Front Suspension
Air/oil telescopic forks, 148mm wheel travel
Rear Suspension
Gas/oil full floater, preload and damping adjustable, 148mm wheel travel
Front Brakes
Drum
LA CUSTOM bikes
250CC. L.A COUSTEM CHOPER
Engine Type …………… Twin, four-stroke
Displacement ………….. 234.00 ccm (14.28 cubic inches)
Compression Ratio …….. 9.4:1
Maximum Power ……….. 17.00 HP (12.4 kW )) @ 7500 RPM
Valves Per Cylinder:……. 2
Bore x Stroke: …………. 2.09 x 2.09 in (53.00 x 53.00 mm)
Gearbox: ………………… 5-speed
Top speed: …………….. 75 mph (120 Km/h)
Fuel Efficiency: …………. 50 mpg, city (21 Km/L)
Wheel Type …………… Alloy
Fuel capacity: ………….. 12.00 litres (3.17 gallons)
Other bikes
110CC HERO HONDA DIO SCOOTER
Engine Type ……………. 4-stroke, air cooled SI Engine
Displacement …………… 109cc
Compression Ratio …….. 10.4:1
Maximum Power ……….. 8 Bhp @ 7500 rpm
Maximum Torque ……… 8.66 Nm @ 5500 rpm
Ground Clearance: …………. 160 mm
Gearbox: ………………… Automatic
Fuel Tank: ….. 6.00 ltrs
Wheel Base …………….. 1238 mm
Headlamp: ……………….. 12V 35/35W
Length: ………….. 1788.00 mm
150CC DISCOVERY
|
|||||||||||||||||||||||||||||||||||||||
180CC PALSER
Engine Type …………… 4Stroke SingleCylinder AirCooled
Displacement ………….. 180 cc
Compression Ratio …….. 9.5:1
Maximum Power ……….. 14.09@8500 BHP@RPM
Maximum Torque ……… 12.76@6500 Nm@rpm
Cylinder Bore …………… 57 mm
Stoke ……………………. 56.4 mm
Ignition ………………….. CDI
Starting …………………. SelfStart KickStart
Wheel Base …………….. 1320 mm
Tyre Size ……………….. Front 90/90 x 17 – Tube, Rear 100/90 x 17 – Tube
Wheel Type ……………. Alloy
600CC DOMINETER
Manufacturer Norton Motorcycle Company
Also called ‘Dommie’
Production 1948–1960s
Engine 497 cc (Model 7 and 88) 596 cc (Model 99) OHV air cooled parallel twin
Transmission Primary by single-row chain; four-speed gearbox; final by chain
Brakes Drum
Wheelbase 55.5 in (1,410 mm)
Seat height 31 in (787 mm)
Weight 395 lb (179 kg) (dry)
Fuel capacity 3.5 gallons (16 litres)
